AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 132 of 146
Property Name Description Valid Values
Offset3 Specifies the location or offset
where the pattern for Match3 is to
be checked.
Range: 0-62
6.9.2 Flow Groups
6.9.2.1 QoS Information Window
Column Name Description
Flow Group ID Lists the ID of Flow Groups available
Description A brief description of the Flow Group.
Classifiers List of Classifiers associated with this Flow Group
6.9.2.1 Add/Modify Flow Group
Property Name Description Valid Values
Flow Group ID
(cannot be
modified)
Specifies the unique identifier for
the Flow Group.
Range: 0-1023
Description Specifies a brief description of the
Flow Group. To set this value, enter an
alphanumeric string from 1-15
characters.
Mark Value This parameter specifies a
replacement value to write into the
DSCP (TOS) field for all packets.
Range: none, 0-63
Priority This parameter specifies the priority
that traffic belonging to this Flow
Group has.
Range: none, 0-7
Remark Priority Specifies whether the value of the
priority parameter is used to set the
egress queue selection for a frame
and also to replace the 802.1p
priority value in the frame, or just
to select the egress queue for the
frame.
• yes
• no
Classifier List Specifies a list of the Classifiers
currently assigned to this Flow
Group.
Select from a list of available
classifier IDs.
6.9.3 Traffic Classeses
6.9.3.1 QoS Information Window
Column Name Description
Traffic Class ID Lists the ID of Traffic Classes available
Description A brief description of the Traffic Class
