AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 41 of 146
Property Name Description Valid Values
• 0-16000000 kbps
• 0-16000 Mbps (decimal point
supported)
• 0-16 Gbps (decimal point
supported)
Priority Specifies the priority value in the
IEEE Standard 802.1p tag control
field that traffic belonging to this
traffic class is assigned.
Range: none, 0-7
Remark Priority Specifies whether the value of the
priority parameter is used to set the
egress queue selection for a frame
and also to replace the 802.1p
priority value in the frame, or just
to select the egress queue for the
frame.
• yes
• no
Flow Group List Specifies a list of the Flow Groups
currently assigned to this Traffic
Class.
Select from a list of available Flow
Group IDs.
6.2.4 Policies
6.2.4.1 QoS Information Window
Column Name Description
Policy ID Lists the ID of Policies available
Description A brief description of the Policy
Traffic Classes List of Traffic Classes associated with this Policy
6.2.4.2 Add/Modify Policy
Property Name Description Valid Values
Policy ID
(cannot be
modified)
Specifies the unique identifier for
the Policy.
Range: 0-255
Description Specifies a brief description of the
Policy. To set this value, enter an
alphanumeric string from 1-15
characters.
Ingress DSCP
Overwrite
Specifies the DSCP value used to
overwrite the DSCP value on the
ingress queue.
Range: none, 0-63
Remark Ingress
DSCP Specifies the conditions under which
the ingress DSCP value is
overwritten.
• zero
• all
