AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 126 of 146
Property Name Description Valid Values
which the frame arrives at the
switch.
name of a pre-defined interface on
the device.
This can also be set to "none".
Source VLAN Specifies the VLAN associated with
the frame when it arrives at the
switch. Only valid in classifiers for
software QoS on egress interfaces.
This can be set by selecting from a
list of available VLANs or "any".
Destination
VLAN
Specifies the VLAN that the frame
will be transmitted to. Only valid in
classifiers for software QoS on
egress interfaces.
This can be set by selecting from a
list of available VLANs or "any".
VLAN Specifies the Destination VLAN that
the packet will be transmitted on.
This can be set by selecting from a
list of available VLANs or "any".
VLAN Priority Specifies the 802.1p VLAN priority
value in the frame.
Range: any, 0-7
Ethernet Format Specifies the Ethernet encapsulation
type of the packet.
• 802.2
• 802.2-Tagged
• 802.2-Untagged
• EthII
• EthII-Tagged
• EthII-Untagged
• NetwareRaw
• NetwareRaw-Tagged
• NetwareRaw-Untagged
• SNAP
• SNAP-Tagged
• SNAP-Untagged
• any
Source MAC
Address
Specifies the source MAC Address
of a packet.
This can be set by entering a MAC
address string using the following
format:
• XX-XX-XX-XX-XX-XX
This value can also be set to "any".
Destination MAC
Address This parameter is the destination
MAC Address of a packet. This can be set by entering a MAC
address string using the following
format:
• XX-XX-XX-XX-XX-XX
This value can also be set to "any".
MAC Type Specifies the type of destination
MAC address on the frame. • L2UCAST
• L2BMCAST
• any
