AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 33 of 146
6.1.3 Scheduling
Setting Description Value
Scheduling Configures the number of expedite
queues. It is used to specify the
scheduling method to use.
• Strict Priority - higher
priority queues are emptied
before any packets are
transmitted from lower
priority queues
• Weighted Priority - packets
are transmitted from all
queues in a round-robin
fashion based on the queue
weights
6.1.4 CoS Priority
Column Name Description Value
Class of Service
(cannot be
modified)
Lists the CoS values available Range: 0-7
Queue Specifies the queue number to
which the CoS value is mapped
Range: 1-4
6.1.5 DSCP Priority
Column Name Description Value
DSCP
(cannot be
modified)
Lists the DSCP values available Range: 0-63
Queue Specifies the queue number to
which the DSCP value is mapped
Range: 1-4
6.1.6 Bandwidth
Column Name Description Value
Interface
(cannot be
modified)
Lists the interfaces (ports and
channels) available The available interfaces will depend
on the device model and
configuration.
• standalone - e1, e2..en
• stacked - 1/e1, 1/e2..1/en,
2/e1, 2/e2..s/en
• channels - ch1, ch2..chn
where:
• n = port/channel number
• s = stack id
Ingress Status Enables/Disables the Rate Limit field • enabled
• disabled
