AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 39 of 146
Property Name Description Valid Values
• ARP
• IPX
• NONIPIPX
• any
This can also be set by entering a 1-
to 5- byte hexadecimal value (00-
FFFFFFFFFF).
Source TCP Port Specifies the TCP source port of a
TCP/IP packet.
Range: any, 0-65535
Destination TCP
Port Specifies the TCP destination port
of a TCP/IP packet. Range: any, 0-65535
TCP Flags Specifies the TCP flags of a TCP/IP
packet. This can be set by selecting one or
more of the following values:
• URG
• ACK
• RST
• SYN
• FIN
• any
Source UDP Port Specifies the UDP source port of an
UDP/IP packet.
Range: any, 0-65535
Destination UDP
Port Specifies the UDP destination port
of an UDP/IP packet. Range: any, 0-65535
6.2.2 Flow Groups
6.2.2.1 QoS Information Window
Column Name Description
Flow Group ID Lists the ID of Flow Groups available
Description A brief description of the Flow Group.
Classifiers List of Classifiers associated with this Flow Group
6.2.2.2 Add/Modify Flow Group
Property Name Description Valid Values
Flow Group ID
(cannot be
modified)
Specifies the unique identifier for
the flow group. Range: 0-1023
Description Specifies a brief description of the
Flow Group.
To set this value, enter an
alphanumeric string from 1-15
characters.
Mark Value This parameter specifies a Range: none, 0-63
