AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 113 of 146
Property Name Description Valid Values
bytemask is 0, the
corresponding bit is ignored.
The default is ff, which
means the classifier matches
against all bits in the byte.
6.8.2 Flow Groups
6.8.2.1 QoS Information Window
Column Name Description
Flow Group ID Lists the ID of Flow Groups available
Description A brief description of the Flow Group.
Classifiers List of Classifiers associated with this Flow Group
6.8.2.2 Add/Modify Flow Group
Property
Name
Description Valid Values
Flow Group ID
(cannot be
modified)
Specifies the unique identifier for
the Flow Group.
Range: 0-1023
Description Specifies a brief description of the
Flow Group. To set this value, enter an alphanumeric
string from 1-15 characters.
Mark Value This parameter specifies a
replacement value to write into
the DSCP (TOS) field for all
packets.
Range: none, 0-63
Action Specifies the action to be
performed on traffic belonging to
the Flow Group.
This can be set by selecting any one of
the following values:
• FORWARD
• FORWARD,SENDMIRROR
• DISCARD
• SENDMIRROR
• SENDMIRROR,SENDVLANPORT
• SENDVLANPORT
• none
Port Specifies the port where traffic is
sent when action=sendvlanport.
The port must belong to the
VLAN specified by the vlan
parameter
This can be set by selecting any one of
the following values:
• port 1 - n (n = number of ports
available)
