AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 142 of 146
Property Name Description Valid Values
Maximum
Bandwidth
Specifies the maximum bandwidth
available to the traffic class.
This can be set by entering a value
using one the following formats:
• 0-16000000 kbps
• 0-16000 Mbps (decimal point
supported)
• 0-16 Gbps (decimal point
supported)
Minimum
Bandwidth Specifies the minimum bandwidth
available to the traffic class. This can be set by entering a value
using one the following formats:
• 0-16000000 kbps
• 0-16000 Mbps (decimal point
supported)
• 0-16 Gbps (decimal point
supported)
Number of
Hashed Flows This parameter specifies the number
of hashed flow groups to be used by
the traffic class.
• 1
• 2
• 8
• 32
• 64
• 128
• 256
• 512
• none
Priority This parameter specifies the priority
that traffic belonging to this traffic
class has.
Range: none, 0-7
RED ID Specifies the Random Early
Detection Curve to be used by the
Random Early Detection algorithm
when dropping packets to avoid
congestion.
Range: none, 0-47
Statistics Counter Specifies whether the statistics
counter for the traffic class counts
either accepted cells or discarded
cells.
• accept
• discard
Weight Specifies the weighting given to this
traffic class when distributing the
bandwidth available on a QoS policy
amongst all traffic classes within the
policy.
• 1, 2, 3, 4, 5, 6, 7, 8, 10, 12,
14, 16, 20, 24, 28, 32, 40, 48,
56, 64, 80, 96, 112, 128, 160,
192, 224, 256, 320, 384, 448,
512, 640, 768, 896, or 1024
