AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 72 of 146
Property
Name
Description Valid Values
bandwidth metering is applied.
Values for premarking and
markvalue in a Flow Group
override the setting for the
Traffic Class.
• none
VLAN Specifies where traffic is sent
when action=sendvlanport.
Traffic is sent out the port
specified by the port parameter,
so the VLAN must contain this
port.
This can be set by selecting from a list of
available VLANs.
Classifier List Specifies a list of the Classifiers
currently assigned to this Flow
Group.
Select from a list of available classifier
IDs.
6.6.3 Traffic Classes
6.6.3.1 QoS Information Window
Column Name Description
Traffic Class ID Lists the ID of Traffic Classes available
Description A brief description of the Traffic Class
Flow Groups List of the Flow Groups associated with this Traffic
Class
6.6.3.2 Add/Modify Traffic Class
Property
Name
Description Valid Values
Traffic Class ID Specifies the unique identifier for
this Traffic Class.
Range: 0-511
Description Specifies a brief description of the
Traffic Class. To set this value, enter an alphanumeric
string from 1-15 characters.
Action Specifies the action to be
performed on traffic belonging to
this traffic class.
This can be set by selecting any one of
the following values:
• FORWARD
• FORWARD,SENDMIRROR
• DISCARD
• SENDMIRROR
• SENDMIRROR,SENDVLANPORT
• SENDVLANPORT
Drop
Bandwidth Determines whether or not to
drop frames exceeding the traffic • NO
