AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 76 of 146
Property
Name
Description Valid Values
Class3 setting.
Default Traffic
Class Ignore
Bandwidth
Class3
Determines whether or not the
metering stage acknowledges any
previous bandwidth class assigned
to flows processed by the default
traffic class.
• yes
• no
Default Traffic
Class Max
Bandwidth
Specifies the maximum bandwidth
available to the default traffic
class.
This can be set by entering a value using
one the following formats:
• 0-16000000 kbps
• 0-16000 Mbps (decimal point
supported)
• 0-16 Gbps (decimal point
supported)
• none
Default Traffic
Class Max
Burst Size
Specifies the burst tolerance for
the default traffic class maximum
bandwidth parameter.
This can be set by entering a value using
one the following formats:
• 0-16777216 bytes
• 0~16384 KB (decimal point
supported)
• 0~16 MB (decimal point
supported)
• 0~0.015628 GB (decimal point
supported)
Note - Byte measures can have the value
b,k,kb,m,mb,g,gb (case insensitive)
Default Traffic
Class Min
Bandwidth
Specifies the minimum bandwidth
reserved for the traffic class.
This can be set by entering a value using
one the following formats:
• 0-16000000 kbps
• 0-16000 Mbps (decimal point
supported)
• 0-16 Gbps (decimal point
supported)
• none
Default Traffic
Class Min
Burst Size
Specifies the burst tolerance for
the default traffic class minumum
bandwidth, or for the default
traffic class maximum bandwidth
when the default traffic class
minimum bandwidth is none.
This can be set by entering a value using
one the following formats:
• 0-16777216 bytes
• 0~16384 KB (decimal point
supported)
