AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 130 of 146
Property Name Description Valid Values
This can also be set by entering a 4-
byte hexadecimal value (00-FF).
IP Protocol Specifies a Layer 4 IP protocol of an
IP packet
This can be set by selecting any of
the following values:
• TCP
• UDP
• NONTCPUDP
• ICMP
• IGMP
• OSPF
• any
This can also be set by entering an
integer from 0-255.
ICMP Type Specifies the ICMP message type to
match against the ICMP type field in
an ICMP packet header.
Range: any, 0-65535
ICMP Code Specifies the ICMP message reason
code to match against the ICMP
code field in an ICMP packet
header.
Range: any, 0-65535
TCP Flags Specifies the TCP flags of the
TCP/IP packet.
This can be set by selecting one or
more of the following values:
• URG
• ACK
• RST
• SYN
• FIN
This can also be set to "any".
Source TCP Port Specifies the TCP source port of a
TCP/IP packet.
Range: any, 0-65535 or a port range
(n-m).
Destination TCP
Port
Specifies the TCP destination port
of a TCP/IP packet.
Range: any, 0-65535 or a port range
(n-m).
Source UDP Port Specifies the UDP source port of a
TCP/IP packet.
Range: any, 0-65535 or a port range
(n-m).
Destination UDP
Port
Specifies the UDP destination port
of a TCP/IP packet.
Range: any, 0-65535 or a port range
(n-m).
Source IPX
Socket Specifies the source IPX socket
number of an IPX packet This can be set by entering a 4-byte
hexadecimal value (0000-FFFF) or by
selecting one of the following:
• NCP
