AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 40 of 146
Property Name Description Valid Values
replacement value to write into the
DSCP (TOS) field for all packets.
Priority This parameter specifies the priority
that traffic belonging to this Flow
Group has.
Range: none, 0-7
Remark Priority Specifies whether the value of the
priority parameter is used to set the
egress queue selection for a frame
and also to replace the 802.1p
priority value in the frame, or just
to select the egress queue for the
frame.
• yes
• no
Classifier List Specifies a list of the Classifiers
currently assigned to this Flow
Group.
Select from a list of available
classifier IDs.
6.2.3 Traffic Classes
6.2.3.1 QoS Information Window
Column Name Description
Traffic Class ID Lists the ID of Traffic Classes available
Description A brief description of the Traffic Class
Flow Groups List of the Flow Groups associated with this Traffic
Class
6.2.3.2 Add/Modify Traffic Class
Property Name Description Valid Values
Traffic Class ID
(cannot be
modified)
Specifies the unique identifier for
this Traffic Class. Range: 0-511
Description Specifies a brief description of the
Traffic Class.
To set this value, enter an
alphanumeric string from 1-15
characters.
Exceed Action Specifies the action to take if the
traffic classes maxbandwidth is
exceeded.
• drop
• remark
Exceed Remark
Value Specifies the DSCP replacement
value for traffic that exceeds the
maxbandwidth.
Range: 0-63
Mark Value Specifies a replacement value to
write into the DSCP (TOS) field for
all packets.
Range: none, 0-63
Maximum
Bandwidth
Specifies the maximum bandwidth
available to the traffic class.
This can be set by entering a value
using one the following formats:
