AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 53 of 146
6.4 AT-9000/24
Topics:
• General
• Traffic Class
• Port Priority
6.4.1 General
Setting Description Value
QoS Status Enables/Disables quality of service
(QoS) on the device
• enabled
• disabled
6.4.2 Traffic Class
Column Name Description Value
Traffic Class
(cannot be
modified)
Lists the CoS values available Range: 0-7
Queue Specifies the queue number to
which the CoS value is mapped Range: 0-3
6.4.3 Port Priority
Column Name Description Value
Port
(cannot be
modified)
Lists the available ports Range: 1-24
Trunk
(cannot be
modified)
Displays the trunk number if the
port is a member of a trunk
• None
• Range: 0-3
Queue Specifies the number of the egress
queue where untagged packets are
to be stored Range: 0-3
Override Specifies whether the CoS value of
ingress tagged packets is to be used
or not
• enabled - tagged packets are
stored in the egress queue
specified in the Queue field
• disabled - packet CoS value
is used to determine the
egress queue
6 Device Support
