AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 91 of 146
Property Name Description Valid Values
This can also be set by entering a 2-
byte hexadecimal number 00-FF.
EIPByte01-16 These parameters each specify the
properties of a single byte field to
match in the Layer 3 header and
data of a non-IPv4 and non-IPv6
packet. The eipbyte01 parameter
must be used as the first byte field,
and additional byte fields must
increment sequentially, for example
eipbyte01, eipbyte02, eipbyte03.
Each field must have a greater offset
than the field that precedes it.
For each byte field you want to
match, specify a byteoffset and a
bytevalue, and optionally, a
bytemask.
• byteoffset is a decimal
number in the range 0 to 65.
This specifies the location of
the byte to match. It refers
to the offset from the start
of Layer 3, after the Layer 2
encapsulation format of an
Ethernet frame.
• bytevalue is a 2-digit
hexadecimal number. This
specifies the value of the
byte at the frame position
determined by the
byteoffset. The classifier
matches packets that have
this value at this location.
• (optional) bytemask is a 2-
digit hexadecimal number.
This specifies an eight-bit
binary mask to apply to the
field. When a bit is set to 1
in the mask, the value of the
bit at the same position in
the byte is used to
determine a match. If the
bytemask is 0, the
corresponding bit is ignored.
The default is ff, which
Each entry can be set by entering
the following value:
, ,
(e.g. 3,AA,FF)
