AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 122 of 146
Column Name Description Valid Values
3648
6.8.7 Quick Setup
Property Name Description Valid Values
Source UDP Port Specifies the UDP source port of an
UDP/IP packet.
Range: 0-65535 or a port range (n-
m).
Default for VOICE: 1719
Default for VIDEO: 1024
Priority Specifies the priority that will be
assigned for this setup.
Range: 0-7
Default for VOICE: 7
Default for VIDEO: 4
Maximum
Bandwidth Specifies the maximum bandwidth
available to this setup. • 0-16000000 kbps
• 0-16000 Mbps (decimal point
supported)
• 0-16 Gbps (decimal point
supported)
Default for VOICE: 128kbps
Default for VIDEO: 256kbps
Port Assignment Specifies a list of ports that will be
affected by this setup.
Select from a list of available Ports.
Default for VOICE: no ports
Default for VIDEO: no ports
6.8.8 Notes
• Values entered for the Maximum Bandwidth traffic class property are rounded up to
the nearest multiple of 648.
• When the Protocol property is configured, the Ethernet Format property should
also be configured.
• When the IP Protocol classifier property is configured to '0', the current firmware
version automatically converts this value to 'NONTCPUDP'.
• Valid values for the VLAN Priority classifier property are 'any' and values in the
range [0-7] inclusive. However, when VLAN Priority is set to 'any', the current
firmware version automatically converts the 'any' value to '4294967295', When this
happens, any attempt to modify the classifier will result in the error message:
"Parameter VLANPRIORITY, value too high; maximum is 7."
• When the TAG Protocol ID classifier property is not set to any value and the VLAN
classifier property is set to 'any', the current firmware version automatically sets the
TAG Protocol ID to '8100'.
