AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 58 of 146
Property Name Description Valid Values
Value value for traffic that exceeds the
maxbandwidth.
Mark Value Specifies a replacement value to
write into the DSCP (TOS) field for
all packets.
Range: 0-63
Maximum
Bandwidth
Specifies the maximum bandwidth
available to the traffic class.
Range: none, 0-1016
Burst Size Specifies the size of a token bucket
for the Traffic Class.
Range: none, 4-512
Priority Specifies the priority value in the
IEEE Standard 802.1p tag control
field that traffic belonging to this
traffic class is assigned.
Range: 0-7
Remark Priority Specifies whether the value of the
priority parameter is used to set the
egress queue selection for a frame
and also to replace the 802.1p
priority value in the frame, or just
to select the egress queue for the
frame.
• yes
• no
Type of Service Specifies the replacement value to
write in the Type of Service field of
IPv4 packets.
Range: none, 0-7
Move TOS to
Priority
Specifies whether or not the value
in the 802.1p priority field will be
replaced with the value in the ToS
priority field on IPv4 packets.
• yes
• no
Move Priority to
TOS
Specifies whether or not the value
in the ToS priority field will be
replaced with the value in the
802.1p priority field on IPv4 packets.
• yes
• no
Flow Group List Specifies a list of the Flow Groups
currently assigned to this Traffic
Class.
Select from a list of available Flow
Group IDs.
6.5.4 Policies
6.5.4.1 QoS Information Window
Column Name Description
Policy ID Lists the ID of Policies available
Description A brief description of the Policy
Traffic Classes List of Traffic Classes associated with this Policy
