Chapter 2: Installing the AT-RPS3000 Chassis and Power Supply Modules

62

Figure 40. Installing a Power Supply Module

Caution

Do not connect the power cord to the module until after you have
installed the module in the chassis. The unit is not hot-swappable
and may be damaged if it is installed while it is powered on.
