AT-RPS3000 Redundant Power Supply Installation Guide
57
Selecting a Location for the AT-RPS3000 Chassis in the Equipment
Rack
The AT-RPS3000 Chassis has to be installed in the same equipment rack
as the x610 Series switches. You may install it above, below, or between
the switches. This may require relocating networking equipment to other
equipment racks if there is currently no available space for the chassis in
the rack.
Figure 33. Positioning the AT-RPS3000 Chassis in the Equipment Rack
This figure illustrates three arrangements that are not recommended for
the chassis and switches. You should not install the devices in adjacent
equipment racks or alongside each other on a tabletop because that would
require twisting the AT-RPS-CBL1.0 Cables, which may damage them. In
addition Allied Telesis does not recommend stacking the chassis and
switches on a table because that could create an unsafe workplace.
Figure 34. Unauthorized AT-RPS3000 Chassis and x610 Series Switch
Installations
Go to “Installing the AT-RPS3000 Chassis in an Equipment Rack” on
page 58.
