Stp and vlan compatibility with tagged ports – Allied Telesis AT-GS950/48 User Manual
Page 80
Chapter 4: STP and RSTP
80
Figure 27. STP and VLAN Compatibility with Tagged Ports
Note
For information about tagged and untagged ports, refer to Chapter
13, “VLAN Overview” on page 158.
T
T
T
T
T
T
Ports blocked by STP
Blocked Data Links
VLAN
1-3
VLAN
1-3
VLAN
1-3
VLAN
1-3
VLAN
1-3
VLAN
1-3
Blocked Data Links
