AT-GS950/48 Web Interface User Guide
137
3. Select either the 802.1Q VLAN or Port-Based VLAN radio button and
enter the respective VLAN ID (1-4093) or VLAN Index (1 - 52).
Note
An error message is generated when you enter a VLAN ID or VLAN
Index which has not been defined, or when you enter a
VLAN ID or VLAN Index without also clicking on the respective radio
button.
4. In the Group MAC Address field, enter a multicast MAC address.
The range is from 01:00:5E:00:01:00 to 01:00:5E:7F:FF:FF.
5. Assign the MAC address a Group Member (or members) by selecting
the check box beside each port number.
To select all ports, click the All button under Group Member.
Note
You can assign a maximum limit of 256 static multicast addresses
on the switch.
6. Click Add.
The Static Multicast Address Table is updated with the new MAC
Address See Figure 47 for a partial view of this page.
Figure 47. Static Multicast Address Table Example
