4a — MONITOR MENU
Monitor Menu: MOTOR
DISPLAY
VARIABLE RANGE DESCRIPTION
Motor RPM -12000–12000 rpm Motor speed in revolutions per minute.
Motor_RPM -12000–12000
Temperature -100–300 °C Temperature sensor readout.
Motor_Temperature -1000–3000
MotorSpeed A 0–12000 rpm Motor encoder phase A speed in revolutions
MotorspeedA 0–12000 per minute.
This can be used to verify that phase A
of the encoder is operating correctly.
MotorSpeed A should equal MotorSpeed B
in a properly operating motor encoder.
MotorSpeed A does not indicate direction.
MotorSpeed B 0–12000 rpm Motor encoder phase A speed in revolutions
MotorspeedB 0–12000 per minute.
This can be used to verify that phase B
of the encoder is operating correctly.
MotorSpeed B should equal MotorSpeed A
in a properly operating motor encoder.
MotorSpeed B does not indicate direction.
Monitor Menu: BATTERY
DISPLAY
VARIABLE RANGE DESCRIPTION
BDI 0–100 % Battery state of charge.
BDI_Percentage 0–100
Capacitor Voltage 0–105 V Voltage of controller’s internal capacitor bank
Capacitor_Voltage 0–6720 at B+ terminal.
Keyswitch Voltage 0–105 V Voltage at KSI (pin 1).
Keyswitch_Voltage 0–10500
