Curtis 1234/36/38 Manual,

OS

11

67

2 3 J U LY 2 0 0 8 D R A F T

4a — MONITOR MENU

Monitor Menu: OUTPUTS

DISPLAY

VARIABLE

RANGE

DESCRIPTION

Analog Out

0–10.0 V

Voltage at Analog output (pin 30).

Analog_Output

0–32767

Digital Out 6

On/Off

Digital Out 6 output on or off (pin 19).

Dig6_Output

On/Off

Digital Out 7

On/Off

Digital Out 7 output on or off (pin 20).

Dig7_Output

On/Off

Driver 1 PWM

0–100 %

Driver 1 PWM output (pin 6).

PWM1_Output

0–32767

Driver 2 PWM

0–100 %

Driver 2 PWM output (pin 5).

PWM2_Output

0–32767

Driver 3 PWM

0–100 %

Driver 3 PWM output (pin 4).

PWM3_Output

0–32767

Driver 4 PWM

0–100 %

Driver 4 PWM output (pin 3).

PWM4_Output

0–32767

PD PWM

0–100 %

Proportional driver PWM output (pin 2).

PD_Output

0–32767

PD Current

0–2.0 A

Current at proportional driver (pin 2).

PD_Current

0–607

5 Volts

0–6.25 V

Voltage at +5V output (pin 26).

5_Volts_Output

0–1023

Ext Supply Current

5–200 mA

Combined current of the external +12V and

Ext_Supply_Current

52–800

+5V voltage supplies (pins 25 and 26).

Pot Low

0–6.25 V

Voltage at pot low (pin 18).

Pot_Low_Output

0–1023
