SECTION 2. PLOT TEMPLATE VIEW
2-10
Any parameter (except derivatives and
integrals) may be used for the X-axis on all four
plot types. However, you must use the same X-
axis parameter for each graph or data trace on
the plot types that allow multiple Y-axis
parameters. Typically Time or Reference Time
is used for the X-axis parameter on a Strip
Chart or Multi-Plot. X-Y plots typically plot two
recorded or calculated parameters against each
other. However, there is no restriction as to
parameter selection except as previously noted
with regard to derivatives and integrals. Any
parameter may be plotted as the Y-axis
parameter(s) except Time or Reference Time
which are only available as an X-axis
parameter.
2.8 “PLOT TITLE” GROUP
At the bottom of the Plot Template view is the
final group labeled “Plot Title”. This is actually a
single edit field containing the plot title that is to
be displayed at the top of the plot. This title
defaults to the comments (if any) in the primary
data file. To change the title just click the
mouse inside the edit box and type the new title.
You may use up to three lines for the plot title.
Once you change the title, changes will be
saved with the plot template and used instead
of the data file comments. However, changing
the primary file will erase the plot title and
default to the comments for the new primary
data file.
FIGURE 2-18. “Plot Title” Group
