Section 5. Settings and Configuration
The window will be updated with the saved settings. Press the Apply button to
update the HydroSense II display with these settings.
5.3 Measurement Colors
HydroSense II Support Software provides three ways to visualize data: Data
tab, Chart tab and Map tab. In each tab, colors are used to represent the value
of volumetric water content (VWC) from a measurement.
5.3.1 Data Tab
The background of each data record is colored based on the VWC measured at
that point.
5.3.2 Chart Tab
The background of the chart is colored with bands to show colors used for each
level of VWC.
5.3.3 Map Tab
Zones in the map are colored based on the average VWC of all the
measurements located within that zone.
Measurements are colored based on the VWC measured at that point.
5-7
