Section 4. Viewing Data
While dragging, the position of the pointer on the map is displayed in the
upper-right of the map. An infotip is displayed to show the number of
contained points and average moisture for the current zone position.
Right-clicking anywhere on the map, or selecting the hand tool from the
toolbox, puts the map back into Drag Mode.
3. Resize Mode
Clicking the resize tool puts the map in Resize mode. Clicking and dragging
on any zone will increase or decrease its radius with the position of the pointer.
This tool can be used to resize zones on the map.
While dragging, an infotip will show the current radius of the zone in meters
with the number of contained zones and the average moisture at this zone size.
Right-clicking anywhere on the map or selecting the hand tool from the
toolbox puts the map back into Drag Mode.
4. Zoom-to-Extents
Clicking the zoom-to-extents button will re-center the view so that all points
for the selected date range are visible.
4-23
