SECTION 13. CR7 MEASUREMENTS

13-9

TABLE 13.3-7. Source Resistances and Signal Levels for YSI #44032 Thermistor Configurations

Shown in Figure 13.3-7 (2V Excitation)

- - - A - - -

- B -

- - - C - - -

T

Rs

Ro

Vs(mV)

Ro@P

Ro

Vs(mV)

(kohms)

(kohms)

(kohms)

(kohms)

-40

884.6

29.0

164

30.0

1

5.5

-20

271.2

27

498

27.8

1

16.5

0

94.98

22.8

1200

23.4

1

39.5

+25

30.00

15.0

2500

15.2

1

82.0

+40

16.15

10.5

3250

10.6

1

106.0

+60

7.60

6.1

3989

6.1

1

129.5

3.

Where possible run excitation leads and
signal leads in separate shields to minimize
transients.

4.

AVOID PVC INSULATED CONDUCTORS
to minimize the effect of dielectric
absorption on input settling time.

5.

Use the CR7 to measure the input settling
error associated with a given configuration.
For example assume long leads are

required but the lead capacitance, Cw, is

unknown. Configure Rf on a length of cable

similar to the measurement. Leave the
sensor end open as shown in Figure 13.3-8
and measure the result using the same
instruction parameters to be used with the
sensor. The measured deviation from 0V is
the input settling error.
