SECTION 13. CR7 MEASUREMENTS

13-8

Table 13.3-6 summarizes maximum lead
lengths for corresponding error limits in six
Campbell Scientific sensors. Since the first
three sensors are non-linear, the voltage error,
Ve, is the most conservative value

corresponding to the error over the range
shown.

MINIMIZING SETTLING ERRORS IN NON-
CAMPBELL SCIENTIFIC SENSORS

When long lead lengths are mandatory in
sensors configured by the user, the following
general practices can be used to minimize or
measure settling errors:

1.

When measurement speed is not a prime
consideration, Instruction 4 (Excite, Delay
and Measure) can be used to ensure ample
settling time for half-bridge, single-ended
sensors.

2.

An additional low value bridge resistor can
be added to decrease the source
resistance, Ro. For example, assume a YSI

non-linear thermistor such as the model
44032 is used with a 30 kohm bridge
resistor, R'f. A typical configuration is

shown in Figure 13.3-7A. The
disadvantage with this configuration is the

high source resistance shown in column 3
of Table 13.3-7. Adding another 1K
resistor, Rf, as shown in Figure 13.3-7B

lowers the source resistance of the CR7
input but offers no improvement over
configuration A because R'f still combines

with the lead capacitance to slow the signal
response at point P. The source resistance
at point P (column 5) is essentially the
same as the input source resistance of
configuration A. Moving Rf' out to the

thermistor as shown in Figure 13.3-7C
optimizes the signal settling time because it
becomes a function of Rf and Cw only.

Columns 4 and 7 list the signal voltages as a
function of temperature with a 5V excitation for
configurations A and C, respectively. Although
configuration A has a higher output signal (5V
input range), it does not yield any higher
resolution than configuration C which uses the
±150 mV input range.

NOTE:

Since Rf' attenuates the signal in

configurations B and C, one might consider
eliminating it altogether. However, its
inclusion "flattens" the non-linearity of the
thermistor, allowing more accurate curve
fitting over a broader temperature range.

TABLE 13.3-6. Maximum Lead Length vs. Error for Campbell Scientific Resistive Sensors

Sensor

Maximum

Model #

Error

Range

Ve(µV)

Length(ft.)

107

0.05oC

0oC to 40oC

5

9651

207(RH)

1%RH

20% to 90%

500

19503

WVU-7

0.05oC

0oC to 40oC

5

8502

024A

3o

@ 360o

1390

2502

227

-

-

-

20003

237

10 kohm

20k to 300k

500

19003

1 based on transient settling

2 based on signal rise time

3 limit of excitation drive
