SECTION 12. PROGRAM CONTROL INSTRUCTIONS

12-4

12:

P89

If X<=>F

01:

25

X Loc DAY

02:

3

>=

03:

6

F

04:

31

Exit Loop if true

13:

P95

End

14:

P87

Beginning of Loop

01:

1

Delay

02:

0

Loop Count

27:

P86

Do

01:

1

Call Subroutine 1

28:

P89

If X<=>F

01:

25

X Loc DAY

02:

3

>=

03:

16

F

04:

31

Exit Loop if true

29:

P95

End

30:

P87

Beginning of Loop

01:

6

Delay

02:

0

Loop Count

36:

P86

Do

01:

1

Call Subroutine 1

37:

P89

If X<=>F

01:

25

X Loc DAY

02:

3

>=

03:

5

F

04:

32

Exit Loop if false

38:

P95

End

39:

P

End Table 1

*

3

Table 3 Subroutines

01:

P85

Beginning of Subroutine

01:

1

Subroutine Number

02:

P18

Time

01:

2

Hours into current year
(maximum 8784)

02:

24

Mod/by

03:

25

Loc [:DAY ]

03:

P95

End

*** 88 IF X COMPARED TO Y ***

FUNCTION
This instruction compares two input locations
and, if the result is true, executes the specified
Command. The comparison codes are given in
Table 12-5.

PAR.

DATA

NO.

TYPE

DESCRIPTION

01:

4

Input location for X

02:

2

Comparison code (Table 12-5)

03:

4

Input location for Y

04:

2

Command (Table 12-2)

Input locations altered: 0
Execution time:

0.6ms

TABLE 12-5. Comparison Codes

Parameter 1

Function

1

IF X = Y

2

IF X

≠ Y

3

IF X

≥ Y

4

IF X < Y

*** 89 IF X COMPARED TO F ***

FUNCTION
This instruction compares an input location to a
fixed value and, if the result is true, performs
the specified Command. The comparison codes
are given in Table 12-5.

PAR.

DATA

NO.

TYPE

DESCRIPTION

01:

4

Input location for X

02:

2

Comparison code (Table 12-5)

03:

FP

Fixed value

04:

2

Command (Table 12-2)

*** 90 STEP LOOP INDEX ***

FUNCTION
When used within a Loop (Instruction 87),
Instruction 90 will increment the index counter
by a specified amount after the first time
through the loop, thus affecting all indexed input
location parameters in subsequent instructions
within the loop. For example, if 4 is specified,
the index counter will count up by 4 (0, 4, 8,
12,...) inside the loop. Instruction 90 does not
affect the loop counter which still counts by 1.
