SECTION 10. PROCESSING INSTRUCTIONS

10-7

Input Storage. The instruction requires the set
of input values to be located contiguously in
Input Storage. The user specifies the location
of the first value and how many total values
exist. The number of input values processed by
each type of calculation (means, variances,
etc.) is independently specified for each type.
The order of the input values determines which
inputs are processed for each type of
calculation.

The instruction does not conform to the CR7's
four instruction types. Data located in Input
Storage is processed, and the results returned
to Input Storage whenever an averaging period
is completed (Parameter 7) or the Output Flag
is set. The instruction controlling the Output
Flag must precede the CV/CR Instruction. The
reason the calculated results are returned to
Input Storage is to allow the user access for
additional processing before storing the values
in Final Storage. Sample Instruction 70 must
be used to transfer final results from Input to
Final Storage.

To accommodate cases where it is desirable to
calculate the statistical quantities over time
periods shorter than the Output Interval, an
averaging period shorter than the Output
Interval may be specified. The final values
obtained at the Output Interval are the properly
weighted average of the values calculated at
the subinterval averaging periods. This feature
allows the recording of statistical data over
longer time periods by removing the effect of
longer period frequencies in the input signals;
i.e., it provides a high pass filter. For example,
assume the variance of an input is desired. It is
determined that the averaging period should not

exceed five minutes due to variation in the
mean over longer time intervals. One approach
is to calculate and record the variance every
five minutes. By specifying the subinterval
averaging period as five minutes and the Output
Interval as one hour, however, the average of
the five minute variances are recorded every
hour. The averaging period is entered as the
number of input samples in Parameter 7 of the
CV/CR Instruction. The number of samples for
a given period is given by:

Number of Samples =

Averaging period in seconds

Table execution interval in seconds

PAR. DATA
NO.

TYPE

DESCRIPTION

01:

2

Number of input values located
sequentially in input memory

02:

2

Number of means desired

03:

2

Number of variances desired

04:

2

Number of standard deviations
desired

05:

2

Number of covariances desired

06:

2

Number of correlations desired

07:

FP

Number of input samples in
averaging period

08:

4

Input storage location of first
value in sequential input string

09:

4

First Input Storage location to
store string of final results

If the specified number of samples in the
averaging period (Parameter 7) exceeds the
actual number of samples occurring in the
Output Interval, the Output Interval becomes the
averaging period.
