Appendix A. CPEC200 Diagnostics

If the value of

valve_flow = NAN, this indicates a problem with the valve flow

measurement. The valve flow is inferred from the pressure drop in the sample

cell as described in Section 4.2.3, Valve Module.

Check the value of

valveControl. This variable determines the size of the

opening of a proportional control valve, from 0 (fully closed) to 1.0 (fully

open). This proportional control valve can be described as an electrically

operated needle valve. In normal operation, when the flow falls below the

setpoint, the CPEC200 will respond by increasing

valveControl. This

increases the opening in the proportional control valve and allows

valve_flow

to rise to the setpoint. Conversely, if the flow is above the setpoint the

CPEC200 will adjust

valveControl downward until the flow matches the

setpoint.

If

valveControl = 0, this indicates the CPEC200 has turned the valve flow off.

There are several reasons the CPEC200 may shut the valve flow off:

No valve is selected

Measured valve flow is NAN

Low supply voltage (see notes on bit 9)

IRGA has been powered down (see notes on bit 8)

If the flow is not at the setpoint, the troubleshooting steps depend on the

situation. There are three cases:

1. Flow is provided from a cylinder of compressed gas. This is the most

common situation. Make sure the cylinder’s regulator is connected to

the proper fitting on the valve module and that it is regulating the

pressure to 10 ± 5 psig. The value of

valveControl should be

between 0.2 and 1.0. If

valveControl = 0.2 and valve_flow is too

high, this indicates the control valve is unable to provide enough

restriction to limit the flow.

The proportional control valve will be fully closed at any value of

valveControl below approximately 0.3.

If

valveControl is 1.0 and the flow is too low and the CPEC200 is

accessible, check the indicator lights on the valve module. One of the

inlet valve lights (Zero Air, CO

2

Span 1, etc.) should be illuminated.

The Flow Control light should also be illuminated. The brightness of

the Flow Control light indicates how hard the proportional control

valve is driven. If

valveControl = 1.0 this light should be full

brightness (approximately as bright as the light that indicates which

inlet valve is selected). If the appropriate valve module indicator

lights are not illuminated, make sure the connector on the side of the

valve module is connected.

2. If the H

2

Ospan valve (6) is selected, the flow is not controlled by the

CPEC200 system, but by the dewpoint generator, which pushes flow

through the valve module to the IRGA. The CPEC200 fully opens the

flow control valve by setting

valveControl = 1. The acceptable range

for

valve_flow is between 0.2 and 2.0 LPM. If the CPEC200 is

accessible, check the indicator lights on the valve module as described

above. Also check the tubing connection between the dewpoint

NOTE

A-15
