3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 74
Tag Description Source Format Length
(decimal)
9F37 Value to provide variability and uniqueness
to the generation of a cryptogram Device b 4
9F40 Additional Terminal Capabilities Device b 5
DFDF70 TAC-default (Terminal Action Codes) Device n 5
DFDF71 TAC-Offline (Terminal Action Codes) Device n 5
DFDF72 TAC-Online (Terminal Action Codes) Device n 5
9F5B Issuer Script Results Device b 0-128
The Merchant Data (F7) Container is included in the response to Report 0xAB – Request EMV
Transaction Data (MAC), which is normally used by the host for receipt printing. The tags in the F7
container are not programmable.
Table 3-75 - Big Block Response to Report 0xAB - Merchant Data Container (F7)
Tag Description Source Format Length
(decimal)
DFDF30 Masked T1 Status Device b 1
DFDF31 Masked T1 Device b Var
DFDF32 Masked T2 Status Device b 1
DFDF33 Masked T2 Device b Var
DFDF34 Masked T3 Status Device b 1
DFDF35 Masked T3 Device b Var
DFDF3E Signature Capture Device b Var 0-7000
5F25 Application Effective Date Card N6 3
5F24 Application Expiration Date Card N6 3
89 Authorization Code Device b 6
5F2A Transaction Currency Code Card N3 2
9F02 Amount, authorized Device N12 6
9F03 Amount, other Device N12 6
9F06 AID - terminal Device b Var 5-16
9F12 Application Preferred Name Card ans Var 1-16
9F1C Terminal ID Device An 8 8
9F39 POS Entry Mode Device N2 1
9C Transaction Type Device N2 1
DFDF40 Signature Required Device b 1
