Generic (Global) OBD2 PID List
Tool
Display
Unit
Value
PID Description
LTFT B3
%
XXX.X
Long Term Fuel Trim-Bank 3
LTFT B4
%
XXX.X
Long Term Fuel Trim-Bank 4
MAF
g/s ;
XXX.XX /
Air Flow Rate from Mass Air
lb/min
XXXX.X
Flow Sensor
MAP
kPa / XXX / XX.X
Intake Manifold Absolute Pressure
PSI
MIL On Time
hrs, min XXXX, XX
Engine Run Time while MIL ON
Monitor Status
-
ICONS on
Monitor Status this Driving Cycle
Display
O2S B1 S1
V
X.XXX
Bank 1 - Sensor 1
O2S B1 S1 mA
mA
X.XXX
Bank 1 - Sensor 1 O2S Current
O2S B1 S1 V
V
X.XXX
Bank 1 - Sensor 1 O2S Voltage
O2S B1 S2
V
X.XXX
Bank 1 - Sensor 2
O2S B1 S2 mA
mA
X.XXX
Bank 1 - Sensor 2 O2S Current
O2S B1 S2 V
V
X.XXX
Bank 1 - Sensor 2 O2S Voltage
O2S B1 S3
V
X.XXX
Bank 1 - Sensor 3
O2S B1 S3 mA
mA
X.XXX
Bank 1 - Sensor 3 O2S Current
O2S B1 S3 V
V
X.XXX
Bank 1 - Sensor 3 O2S Voltage
O2S B1 S4
V
X.XXX
Bank 1 - Sensor 4
O2S B1 S4 mA
mA
X.XXX
Bank 1 - Sensor 4 O2S Current
O2S B1 S4 V
V
X.XXX
Bank 1 - Sensor 4 O2S Voltage
O2S B2 S1
V
X.XXX
Bank 2 - Sensor 1
O2S B2 S1 mA
mA
X.XXX
Bank 2 - Sensor 1 O2S Current
O2S B2 S1 V
V
X.XXX
Bank 2 - Sensor 1 O2S Voltage
O2S B2 S2
V
X.XXX
Bank 2 - Sensor 2
O2S B2 S2 mA
mA
X.XXX
Bank 2 - Sensor 2 O2S Current
O2S B2 S2 V
V
X.XXX
Bank 2 - Sensor 2 O2S Voltage
O2S B2 S3
V
X.XXX
Bank 2 - Sensor 3
O2S B2 S3 mA
mA
X.XXX
Bank 2 - Sensor 3 O2S Current
O2S B2 S3 V
V
X.XXX
Bank 2 - Sensor 3 O2S Voltage
O2S B2 S4
V
X.XXX
Bank 2 - Sensor 4
O2S B2 S4 mA
mA
X.XXX
Bank 2 - Sensor 4 O2S Current
O2S B2 S4 V
V
X.XXX
Bank 2 - Sensor 4 O2S Voltage
O2S Location
-
O2S11
Oxygen Sensor, Bank 1, Sensor 1
O2S Location
-
O2S12
Oxygen Sensor, Bank 1, Sensor 2
O2S Location
-
O2S13
Oxygen Sensor, Bank 1, Sensor 3
O2S Location
-
O2S14
Oxygen Sensor, Bank 1, Sensor 4
O2S Location
-
O2S21
Oxygen Sensor, Bank 2, Sensor 1
