CODE RETRIEVAL PROCEDURE

The CanOBD2&1 Scan Tool will auto-
matically re-link to the vehicle’s com-
puter every 30 seconds to refresh the
data being retrieved. When data is
being refreshed, the message “One
moment Auto – link in progress” is
shown on the display. This action
repeats as long as the CanOBD2&1
Scan Tool is communicating with the
vehicle’s computer.

The CanOBD2&1 Scan Tool will dis-
play a code only if codes are present
in the vehicle’s computer memory. If
no codes are present, a “No DTC’s
are presently stored in the vehicle’s
computer” message is displayed.

The CanOBD2&1 Scan Tool is capable of retrieving and storing
up to 32 codes in memory, for immediate or later viewing.

8. To read the display:

Refer to Display Functions on page 12 for a description
of display elements.

A visible

icon indicates that the CanOBD2&1 Scan Tool is

being powered through the vehicle’s DLC connector.

A visible

icon indicates that the CanOBD2&1 Scan Tool is

linked to (communicating with) the vehicle’s computer.

The I/M Monitor Status icons indicate the type and number of
Monitors the vehicle supports, and provide indications of the cur-
rent status of the vehicle’s Monitors. A solid Monitor icon indi-
cates the associated Monitor has run and completed its testing.
A blinking Monitor icon indicates the associated Monitor has
not run
and completed its testing.

The upper right hand corner of the
display shows the number of the code
currently being displayed, the total
number of codes retrieved, the type
of code (G = Generic; M = Enhanced
or Manufacturer specific), and
whether or not the displayed code
commanded the MIL on. If the code
being displayed is a PENDING code,
the PENDING icon is shown.

The Diagnostic Trouble Code (DTC) and related code definition
are shown in the lower section of the display.
