You Can Do It!

EASY TO USE - EASY TO VIEW - EASY TO DEFINE

2

CanOBD2&1

E

Easy To Use . . . .

Connect the CanOBD2&1 Scan Tool
to the vehicle’s test connector.

Turn the ignition key "On.”

Press the POWER/LINK button.

Easy To View . . . .

The CanOBD2&1 Scan Tool retrieves
stored codes, as well as Freeze Frame
data and I/M Readiness status (OBD2
systems only).

Codes, I/M Readiness status and
Freeze Frame data are displayed on the
CanOBD2&1 Scan Tool’s display
screen. System status is indicated by
LED indicators.

Easy To Define . . . .

Read code definitions from the
CanOBD2&1 Scan Tool’s display.

View Freeze Frame data (OBD2 sys-
tems only).

View, record and playback live data
(OBD2 systems only).
