04 cab platform assembly – Ag-Bag LX1214 User Manual
Page 79
Description
Quantity
Part No.
Item
Btnhdblt, 3/8-16 x 1-1/4 Stainless Steel
30
907984
1
Washer, 1/2 Wide Flat Stainless Steel
16
907466
2
Washer - Stainless Steel Flat 3/8 Wide
56
907465
3
Hhdblt, 1/2-13 x 1-1/2 Stainless Steel
8
907424
4
Hhdnut, 1/2-13 Stainless Steel Nylock
8
907392
5
Nut: Hex Nylon Lk 3/8-16
42
906400
6
Bolt: Hhd G5 1/4 x 3/4 In.
1
904863
7
Carblt - 3/8-16 x 1 1/4 in.
4
903693
8
Hhdblt - G5 1/2 x 1-3/4 in.
3
903518
9
Hhdblt - G5 3/8x1 in. Yellow Zinc
4
902300
10
Washer - Flat 3/8 in. SAE
8
901105
11
Washer - Lock 1/4 in.
1
900502
12
Washer - Flat 1/2 in. Std
6
900497
13
Hhdnut, 1/2-13
3
900369
14
Plate - Upper Platform Mount
1
42.0800896
15
Platform, Cab Upper Assy Mb
1
42.0800892
16
Rail Assembly Steps CE Platform Mb
1
42.0800888.8
17
Rail Wdmt CE Platform Mb
1
42.0800886.8
18
Platform Wdmt, Mb11014
1
42.0800883
19
Panel, Platform Main Floor
1
42.0800881
20
Riser, Upper Cab Platform Mb
1
42.0800271
21
Bumper, Rubber Door
1
21.21884
22
LX1214
- 79 -
42.0802220A Issue Date: 08/14
Section 4
4.04 Cab Platform Assembly
