Ag-Bag LX1214 - Manual (Page 75)

Description Quantity Part No. Item
Foam Seal - 1x1 Self Adhesive (Order Per Foot) 15 Ft 21.23540 1
Trim, Cooler Door Seal (Order Per Foot) 16 Ft 42.0800171 2
Panel, Fan Shroud 1 42.0800279 3
Rotary Lock (LH) 1 42.0800470 4
Plate, Door Latch Mount 1 42.0800473 5
Weldment, Door Latch Release 1 42.0800480 6
Door Prop 1 42.0800630 7
Spacer .675 Od x .386 Id x 1.000 1 42.0800679 8
Panel, Fan Guard 2 42.0800695 9
Bushing, Door Latch Spring (bronze) 3 42.0800785 10
Panel, Engine Cooler (top) 1 42.0800911 11
Panel, Engine Cooler (hinge Side) 1 42.0800912 12
Panel, Engine Cooler (latch Side) 1 42.0800913 13
Angle, Engine Cooler Mount Wldmt (hinge Side) 1 42.0800914 14
Angle, Engine Cooler Mount Wldmt (latch Side) 1 42.0800915 15
Angle, Engine Cooler (top & Bottom) 2 42.0800916 16
Plate, Striker Stud Mount 1 42.0800918 17
Cooler Door Weldment 1 42.0800919.5 18
Hinge - Cooler Door X1114 1 42.0800924.5 19
Hhdblt, Gr 5, 3/8-16 x 1-1/4 10 902367 20
Clip Nut, 3/8-16 4 904172 21
Hhdblt, 1/4-20 x 3/4 Gr 5 12 904863 22
Hhdblt, Stainless Steel 1/4-20 x 1-1/4 1 907233 23
Washer, Stainless Steel 1/4 Flat 28 907234 24
Carblt, 3/8-16 x 1 Stainless Steel 8 907337 25
Washer, Stainless Steel 5/16 Flat 4 907379 26
Washer, Stainless Steel 3/8 Flat 2 907380 27
Hhdnut, 1/4-20 Stainless Steel 1 907384 28
Hhdnut, 1/4-20 Stainless Steel Nylock 17 907389 29
Hhdnut, 5/16-18 Stainless Steel Nylock 4 907390 30
Hhdnut, 3/8-16 Stainless Steel Nylock 35 907391 31
Washer, 3/8 Wide Flat Stainless Steel 68 907465 32
Btnhdblt, 3/8-16 x 1 Stainless Steel 31 907467 33
Btnhdblt, 3/8-16 x 1-1/2 Stainless Steel 2 907468 34
Btnhdblt, 3/8-16 x 1-3/4 Stainless Steel 2 907469 35
Flatwasher, 3/8 Wide Heavy Stainless Steel 7 907533 36
Btnhdblt, 3/8-16 x .75 Stainless Steel 2 907558 37
Btnhdblt, 1/4-20 x 1-1/2 Stainless Steel 4 907614 38
Btnhdblt, 5/16-18 x 1 Stainless Steel 4 907615 39
Spring, Comp. 29/32od x 2-3/4lg 1 907954 40
LX1214 - 75 - 42.0802220A Issue Date: 08/14
Section 4
4.02 Cummins Engine Radiator Shroud Assembly
