Ag-Bag LX1214 - Manual (Page 277)

Description Quantity Part No. Item
Valve, Hydraulic Engine End 1 42.0800137 1
Adapter, -10 ORB x 1/2 in. MJIC 18 32.02101 2
Adapter, -06 ORB x 3/8 in. MJIC 4 07.17911 3
Adapter, -10 ORB x 6 MJIC, 90° 1 907775 4
Adapter, -12 MJIC x -10 ORB 2 32.02089 5
Shuttle Valve, O-Ring 1 32.04712 6
Weldment, Valve Mounting Engine End (Front) 1 42.0800728 7
Plate, Valve Mounting Engine End (Top) 1 42.0800727 8
Decal, Hydraulic Valve Bank 1 42.1100063 9
Handle, Short P70 Valve 6 42.0800555 10
Coil AR 21.32122 11
Seal Kit AR 21.32124 12
Intersection Seal Kit AR 21.32123 13
Actuator Kit AR 42.0801173 14
LX1214 - 277 - 42.0802220A Issue Date: 08/14
Section 10
10.07 Hydraulic Valve Assembly Engine End
