07 cummins engine clutch assembly – Ag-Bag LX1214 User Manual
Page 57
Description
Quantity
Part No.
Item
Adapter, -08 ORB x 1/2 M JIC
2
09.74155
1
Flange Kit - 2 in. Code 61
1
32.03793
2
Elbow - 2 in. Code 61 x HB
1
32.03995
3
Clutch, Hpto 15
1
42.0800021
4
Coupling, Flywheel
1
42.0800092
5
Flange, Flywheel Coupling
1
42.0801244
5a
Element, Flywheel Coupling
1
42.0801245
5b
Collar, Flywheel Coupling
1
42.0801246
5c
Hub, Flywheel Coupling
1
42.0801247
5d
Socket Hd Cap Screw M10-1.5 x 35mm Gr 12.9
10
908191
5e
Socket Hd Cap Screw M16-2 x 40mm Gr. 88
1
908192
5f
Bracket - Hi Pressure Fltr
1
42.0800622
6
Brkt: Clutch Hyd Valve, Cummins
1
42.0801387.5
7
Filter, Hyd Element
1
42.1541961
8
Head, Filter
1
42.1541978
9
Indicator - Filter Electrical
1
42.1541979
10
Hhdblt, Gr 5, 5/8-11 x 2
4
904253
11
Hhdblt - Stainless Steel 5/16-18 x 1
6
907349
12
Hhdnut, 5/16-18 Stainless Steel Nylock
2
907390
13
Lockwasher, 5/16 Stainless Steel
4
907411
14
Lockwasher, 5/8 Stainless Steel
6
907419
15
Hhdblt, 5/8-11 x 1-1/2 Stainless Steel
2
907432
16
Washer, 5/16 Wide Flat Stainless Steel
6
907464
17
Hhdblt, Gr 8, 7/16-14 x 1-1/2
12
907658
18
Sochdcs, 1/2-13 x 1-1/2 Gr 8
8
907878
19
Controller, Clutch Display (Included With Item 4)
1
42.0800779
20
Controller, Clutchmaster HPTO (Included With Item 4)
1
42.0800780
21
Clutch Valve Manifold, PT Tec (Included With Item 4)
1
42.0800584
22
Pressure Reducing Valve, HPTO
1
42.0900890
22a
Temperature Switch, Clutch
1
42.0801158
22b
Pressure Sensor, HPTO
1
42.0800783
22c
Flow Control Valve, HPTO
1
42.0900889
22d
Coil, Clutch Manifold
2
42.0801160
22e
Prop Relief Valve, Clutch
1
42.0801159
22f
Harness Kit, HPTO Clutch (Included With Item 4)
1
42.0801162
23
LX1214
- 57 -
42.0802220A Issue Date: 08/14
Section 3
3.07 Cummins Engine Clutch Assembly
