Description
Quantity
Part No.
Item
Screw, M5 x 12 mm
2
21.22669
1
Washer
2
21.22670
2
Shaft
1
32.61415
3
Link
1
32.61416
4
Shim
2
21.22658
5
Clip
2
32.61417
6
Wiper Motor
1
32.61418
7
Arm
1
32.61419
8
Lock Nut
1
32.61420
9
Bracket
1
21.22645
10
Lockwasher, 1/4 in.
3
21.22674
11
Cap Screw, 1/4 in. x 5/8 in.
3
32.61421
12
Screw, M8 x 16 mm
1
21.22647
13
Plug
1
32.61422
14
Flange Nut, M6
1
21.22649
15
Support
1
21.22650
16
Screw, M8 x 40 mm
2
21.22651
17
Stud
1
32.61423
18
Shim
1
21.22658
19
Lock Nut
1
21.22659
20
Lock Nut
1
21.22663
21
Weld Nut
1
21.22672
22
Wiper Arm
1
32.61424
23
Lock Nut
1
32.61425
24
Screw
1
32.61426
25
Wiper Blade
1
32.61427
26
Cap
1
21.22655
27
Nut
1
32.61428
28
Washer
1
21.22654
29
Washer
1
21.22653
30
LX1214
- 167 -
42.0802220A Issue Date: 08/14
Section 6
6.30 Windshield Wiper
