Ag-Bag LX1214 - Manual (Page 300)

Dust Shield.....117
Dye: Oil-Glo 44, 4 OZ......285
Dye: Oil-Glo 44, 8 OZ......285
E
Elastic Pin.....239
Elbow - 2 in. Code 61 x HB.....57, 265
Elbow - 45 16 MJIC x 1 in. NPT.....261
Elbow - 90d 3/8 NPTF M/F.....265
Elbow - 90d 8 x 7.....47
Elbow -90d 3/8 in. Tube - 3/8 in. NPT.....261
Elbow 90d Union 3/4-16 37 Deg.....31, 271
Elbow, -04 MJIC x FJIC.....229
Elbow, -04 ORB x 1/4 MJIC.....229
Elbow, -06 FORB x -06 MORB.....279
Elbow, -08 ORB x 1/2 in. MJIC.....267
Elbow, -08 ORB x 1/2 M JIC.....31, 33
Elbow, -08 ORB x 1/2 MJIC.....51
Elbow, -10 ORB x 1/2 MJIC.....269
Elbow, -12 ORB x -08 Mjic.....217
Elbow, -16 ORB x -16 MJIC.....65
Elbow, 1 in. FJIC x MJIC 45°.....65
Elbow, 1 MJIC x Swivel 90°.....65
Elbow, 1/2 MPT x -06 MJIC.....89
Elbow, 1/2 MPT x 3/4 MJIC.....93
Elbow, 1/2 NPT Street 90d.....43, 261
Elbow, 1/2 NPT x 1/2 MJIC.....93, 269
Elbow, 1/4 in. Air Union.....103
Elbow, 1/4 in. MPT x 1/4 in. Tube.....103
Elbow, 1/4 in. Tube x 1/8 in. FPT.....103
Elbow, 1/4 MPT x 3/8 Tube.....101
Elbow, 1/4 NPT Street.....171
Elbow, 1/8 FPT x 1/8 MPT.....261
Elbow, 1/8 Fpt x 1/8 MPT.....113, 169
Elbow, 1/8 in. MPT x 1/4 in. Tube.....103
Elbow, 3/4 in. MJIC x Swivel 90°.....65
Elbow, 3/4 MJIC x Swivel 90.......43, 51, 261,
271
Elbow, 3/8 in. Air Union.....103
Elbow, 3/8 MJIC x 3/8 Jic Swv.....171
Elbow, 3/8 MPT x 1/2 MPT.....109
Elbow, 3/8 MPT x 3/8 MPT.....101
Elbow, 45 1/8 MPT x FPT.....71, 169
Elbow, 45° -12 MJIC x JIC Swivel.....65
Elbow, 45° 12 Mjic x 12 ORB.....217
Elbow, 90 1/2 in. JIC Swivel......97, 181, 221,
271
Elbow, 90d -04 ORB x -06 JIC.....171
Elbow, 90d 37° Flare 3/4.....217
Elbow, 90° 3/4 in. MPT x 3/8 in. Hose
Barb.....209
Elbow, 90° Swivel 1/2 in. FPT x 3/8 in. Hose
Barb.....209
Elbow, Street 90° 3/4 in......209
Elbow: -08 ORB x 1/2 MJIC.....181
Elbow: 1/2 MPT x 3/8 Tube.....91
Elbow: 1/4 MPT x 3/8 Tube.....93, 95, 97, 99,
271
Elbow: 1/8 Fpt x 1/4 Tube.....113
Elbow: 1/8 MPT x 1/4 Tube.....113
Elbow: 2 in. 45 Deg Female.....261
Elbow: 3/8 MPT x 3/8 Tube.....99, 101, 109
Elbow: 3/8 Tube Union.....95
Elbow: 45d 7 in......47
Elbow: 90d 3/8 In.tube - 3/8 In. PIP.....265
Elbow: Reducing 7 x 6 45d.....47
Electrical Connector Accessory.....119
Electrical Connector Assembly.....119, 147
Electrical Connector Housing.....119
Electrical Connector Seal.....119, 147
Electrical Connector Terminal.....119, 147
Element.....93
Element, Flywheel Coupling.....57
Enclosure.....289
End Plate.....239
Evaporator.....123
Exernal Snap Ring.....237
Ext Ernal Snap Ring.....237
Extension - Bb Outrigger Mb11000.....205
Extension: Tunnel 12 Ft.....197
External Snap Ring.....237
F
Fan.....121
Fan - 42 in. Asm W/hub.....55
Feed Table Lock Pin Assembly (Consists Of
Items 7 thru 10).....37
Feed Table Pin Assembly.....37
Feedtable Lock Pin Asm.....9
Feedtable Wing Wld CE.....175
Feedtable Wing Wld EE.....175
Filler/breather - High Neck.....265
Filter.....123, 261
Filter (Primary) (Included With Air
Cleaner).....47
Filter (Safety) (Included With Air Cleaner)...47
Filter - Hydraulic P551553.....217
Filter Asm, Return Tank 4215/4240.....261
Filter Asm, Top Tank Case Drain.....261
Filter Bowl.....209
Filter Element.....261
Filter, Hyd Element.....57
Filter, Oil Tank Breather.....261
Filter: QSX Engine Oil.....43
Filter: QSX Fuel.....43
Fitting.....117
Fitting -12 Flare/27m ORST Viton.....43
Fitting, -6 ORB To #6 A/C.....69
Fitting, -6 ORB To #6 A/c.....51
Fitting, 1/2 MPT x 3/4 Hb Brass.....43
Fitting, 1/2 MPT x 5/8 HB Brass.....43, 261
Fitting, 1/4 NPT x 3/8 HB Brass.....43, 51, 171
Fitting, 1/8 in. NPT x 1/4 in. Int Hex.....103
Fitting, Grease, 1/8-Ptf.....269
Fitting, Male #10 SAE SAE/#8
Refrigerant.....51, 69
Flange Elbow, 2 in. Code 61.....65
Flange Kit - 2 in. Code 61.....57
Flange Kit, 2 in. Code 61.....65
Flange Kit, SAE 3/4 in. Code 61.....55
Flange Kit, SAE, 1-1/2 in. Code 62.....65
Flange Nut.....127, 151, 153, 161
Flange Nut, M6.....167
Flange, Flywheel Coupling.....57
Flange: Kit - 2 In. Code 61.....265
Flatwasher, 1/2 Hardened.........93, 169, 185,
187, 213, 225
Flatwasher, 3/4 in. Sae.....45
Flatwasher, 3/8 Hardened.....183, 225
Flatwasher, 3/8 Wide Heavy Stainless
Steel.....73, 75, 183, 215
Flatwasher, 3/8 Wide Stainless Steel.....193
Flatwasher, 3/8 x 2 Od Stainless Steel.....215
Flatwasher, 7/16 Stainless Steel.....199
Flng Blt, Gr8, 3/4-10 x 3.....185, 187
Flow Control Valve, HPTO.....57, 281
Foam Seal - 1x1 Self Adhesive (Order Per
Foot).....75
Forage Dam Wldmnt.....183
Frame, Tunnel Cleanout 14 Ft.....185
Frame: Engine Skid Complete Blk.....45
Frame: Feed Table.....169
Free Coupling Device (Includes 38-43).....28
Fuel Sender, Mp3.....89
Fuse, 10A.....251
Fuse, 15A.....251
Fuse, 25A.....251
Fuse, 5A.....251
FX Housing Sub Assembly.....59
G
Gang Bolt.....147
Gasket.....135, 209, 261
Gasket .25 in. x .50 in......247
Gasket, Cap EPDM CP19438-EPR.....209
Gasket, Fan Pump.....171
Gasket, Receptacle HDP24.....249
Gauge, 100# 2.5 in. Liquid Stainless
Steel.....211
Gauge, Filter Minder.....261
Gease Fitting (Optional).....173
Gladhand Seal, Blue Service.....91
Gladhand Seal, Red Emergency.....91
Governor, Air Compress.....43
Graphics Panel.....149
Grease Fitting, 1/4-28.....31, 33, 191
Grease Zerk 1/4-28.....205
Grease Zerk, 1/4-28.....201
Grease Zerk, 1/8 in. NPT Female.....223
Grommet.....155
Grommet, 5/8 Hole.....95
Grommet, 7/8 Hole.....95
Grommet, Tail Light.....243
Grommet, Taillight.....71
Grz Zerk - 1/8 NPT Female.....169
Grz Zerk - 1/8npt Female.....269
Guard, Beater Bar Chain Roller.....223
Guard: Module.....9
Guide Block, Anchor Pointer.....193
Guide Panel - Belt Shield 11000.....225
Guide Pin.....27
Guide Ring.....27
Guide: Fdtbl Belt 7/8x2x24 UHMW.....169
H
Hair Pin, Stainless Steel.....191
Hairpin, .177 in. x 3-11/16 in......35
Handle.....135
Handle (Cab S/N 508668 & Before).....165
Handle (Cab S/N 508669 & After).....165
Handle, Short P70 Valve.....277
Handle, Short Stainless Steel.....73, 77
Harness Kit, HPTO Clutch (Included With Item
4).....57
Harness, Arm Rest.....253
Harness, Cab End Lights.....253
Harness, Cab End Valve.....253
42.0802220A Issue Date: 08/14 - 300 - LX1214
Part Description Index
(continued)
