Description
Quantity
Part No.
Item
Nut, Hex Lock Flange, 5/16-18 Nylock Black Zinc
2
907625
1
Bolt, Hex, 5/16-18 x 1 in. Stainless Steel
2
907349
2
Nut, Hex Lock, 3/8-16 Nylock
26
906400
3
Bolt, Hex, 3/8-16 x 1-1/2 in.
4
903848
4
Bolt, Hex, 3/8-16 x 1 in. Gr 5 Yellow Zinc
22
902300
5
Washer, Flat, 3/8 in.
26
900495
6
Tube, Platform Rail Brace
2
42.0800485
7
Hinge, Platform Mount
3
42.0800458.8
8
Railing, Upper Platform Weldment
1
42.0800454
9
Platform, Upper Weldment
1
42.0800451
10
Handle, Short Stainless Steel
1
32.04572
11
LX1214
- 77 -
42.0802220A Issue Date: 08/14
Section 4
4.03 Upper Platform Assembly
