17 bag boom frame assembly – Ag-Bag LX1214 User Manual
Page 201
Description
Quantity
Part No.
Item
Bolt, Button Hd, 1/4-20 x 3/4 in. Stainless Steel
2
907613
1
Cotter Pin, 3/16 x 2 in. Stainless Steel
4
907427
2
Nut, Hex Lock, 1/4-20 Nylock Stainless Steel
2
907389
3
Restrictor, .062
2
907203
4
Nut, Hex Lock, 3/8-16 Nylock
2
906400
5
Bolt, Hex, 3/8-16 x 7/8 in. Gr 5
2
903699
6
Bolt, Hex, 1/2-13 x 1-1/2 in. Gr 5
4
903306
7
Grease Zerk, 1/4-28
2
903162
8
Machined, Bushing, 1-1/2 in.
4
900514
9
Washer, Lock, 1/2 in.
4
900506
10
Washer, Lcok, 3/8 in.
2
900504
11
Cable, 3/8 in. x 50 Ft. With Hook
1
42.1590063
12
Winch, Planetary Hydraulic 2 Stage
1
42.1541974
13
Motor Assembly
AR
42.0801181
13a
Clutch Assembly
AR
42.0801182
13b
Winch Service Kit
AR
42.0801183
13c
Winch Motor Service Kit
AR
42.0801185
13d
Spacer, Bag Boom Bushing
1
42.1206093
14
Spacer, Wheel Column, Bronze
1
42.1201023
15
Bushing, Wheel Column
2
42.1201020
16
Mast Bag Boom 12 & 14 Ft.
1
42.1060178
17
Outrigger, Bag Boom 12 & 14 Ft.
1
42.1060177
18
Pad, Slide, Bag Boom, Side
2
42.0901503
19
Pin, Bag Boom Outrigger
1
42.0901355
20
Pad, Slide, Bag Boom, Lower
1
42.0901312
21
Hydraulic Cylinder, 2.5 in. x 10 in. ORB
2
42.0800720
22
Pin, Hydraulic Cylinder
4
42.1542091
22a
Decal, Warning Hand Crushing
2
40.00472
23
Clip Hydraulic Line
2
322848B1
24
Adapter, -1/2 in. MJIC x -16 ORB
2
32.02103
25
Adapter, -06 ORB x 3/8 in. MJIC
2
07.17911
26
Seal Kit, Hydraulic Cylinder
1
42.0800717
27
Hoses (Not Shown)
1
Hose, Hydraulic, 3/8 in. Boom Swing Base
1
42.0800572
(Rotate In Valve Top Port To Cylinder Base)
1
Hose, Hydraulic, 3/8 in. Boom Swing Rod
1
42.0800573
(Rotate Out Valve Bottom Port To Cylinder Rod End)
1
Hose, Hydraulic, 1/2 in. Boom Winch Short
1
42.0800574
(Winch Up Valve Top Port To Winch Motor Bottom Port)
1
Hose, Hydraulic, 1/2 in. Boom Winch Long
1
42.0800575
(Winch Down Valve Bottom Port To Winch Motor Top Port)
1
LX1214
- 201 -
42.0802220A Issue Date: 08/14
Section 7
7.17 Bag Boom Frame Assembly
