Page 73
Description
Quantity
Part No.
Item
Overflow Bottle - 4 Qt Rad
1
21.24166
1
Handle, Short Stainless Steel
1
32.04572
2
Panel, Engine Compartment
1
42.0800275
3
Brace, Engine Compartment Roof
1
42.0800296
4
Brace, Engine Compartment Roof EE
1
42.0800297
5
Brace, Engine Compartment Roof CE
1
42.0800298
6
Brkt - Air Cleaner Mtg
1
42.0800411
7
Wdmt: Front Engine Guard
1
42.0801319.5
8
Panel: Multi Color Lights EE
1
42.0801328.5
9
Roof: Engine Compartment Black
1
42.0801329.5
10
Washer, 5/16 Flat
8
900494
11
Washer - Lock 5/16 in.
1
900503
12
Hhdblt, Gr 5, 5/16-18 x 1-1/4
4
904464
13
Hhdnut, 5/16-18 Nylock
4
906483
14
Washer, Stainless Steel 5/16 Flat
11
907379
15
Hhdnut, 5/16-18 Stainless Steel Nylock
5
907390
16
Hhdnut - Stainless Steel Nylok 3/8-16
33
907391
17
Hhdnut, 1/2-13 Stainless Steel Nylock
6
907392
18
Washer, 1/2 Stainless Steel Flat
12
907395
19
Hhdblt, 1/2-13 x 1-1/2 Stainless Steel
6
907424
20
Washer - Stainless Steel Flat 3/8 Wide
53
907465
21
Btnhdblt, 3/8-16 x 1 Stainless Steel
13
907467
22
Btnhdblt, 3/8-16 x 1-1/2 Stainless Steel
2
907468
23
Flatwasher, 3/8 Wide Heavy Stainless Steel
13
907533
24
Hhdblt, Gr 8.8, M8-1.25 x 25mm
1
907568
25
Btnhdblt, 5/16-18 x 1-1/4 Stainless Steel
5
907983
26
Btnhdblt, 3/8-16 x 1-1/4 Stainless Steel
18
907984
27
LX1214
- 73 -
42.0802220A Issue Date: 08/14
Section 4
4.01 Cummins Engine Shroud Assembly
