Description
Quantity
Part No.
Item
Hose, Hydraulic, 3/8 in. Boom Extend Long
1
42.0800576
(Boom Retract Valve Bottom Port To Cylinder Rod End)
1
Hose, Hydraulic, 3/8 in. Boom Extend Short
1
42.0800577
(Boom Extend Valve Top Port To Cylinder Base)
1
Hose, Hydraulic, 3/8 in. Boom Tilt Base
1
42.0800578
(Boom Up Valve Top Port To Cylinder Base)
1
Hose, Hydraulic, 3/8 in. Boom Tilt Rod
1
42.0800579
(Boom Down Valve Bottom Port To Cylinder Rod End)
1
42.0802220A Issue Date: 08/14
- 202 -
LX1214
Section 7
7.17 Bag Boom Frame Assembly
