Page 47
Description
Quantity
Part No.
Item
Air Cleaner
1
42.0800412
1
Cover (Included With Air Cleaner)
1
42.0801143
1a
Filter (Primary) (Included With Air Cleaner)
1
42.0800816
1b
Filter (Safety) (Included With Air Cleaner)
1
42.0800817
1c
Vacuator Valve (Included with Air Cleaner)
1
42.0801144
1d
Mtg Band - Air Cleaner
2
42.0800413
2
Elbow - 90d 8 x 7
1
42.0800415
3
Bracket, Air Cleaner Mount
1
42.0800512
4
Muffler: 6 in.
1
42.0801323
5
Pre-Cleaner includes clamp (use clamp 908657 for Service)
1
42.0801335
6
Clamp: 6 in. Bent Bolt
2
42.0801336
7
Tube: Alum 7.0 OD. x 12.0 x 1/8 W
1
42.0801340
8
Tube: Alum 7.0 OD. x 25.0 x 1/8 W
1
42.0801341
9
Tube: Alum 7.0 OD. x 13.87 x 1/8 W
1
42.0801342
10
Bracket: Air Intake Support
1
42.0801344.5
11
Plate: Air Intake Support
1
42.0801345.5
12
Elbow: Reducing 7 x 6 45d
1
42.0801349
13
Tube: Exhaust QSX
1
42.0801351
14
Reducer: Pre Cleaner 9 x 8
1
42.0801352
15
Elbow: 45d 7 in.
2
42.0801353
16
Wdmt: 12 in. Muffler Mount
2
42.0801355
17
Outlet: Exhaust
1
42.0801358
18
Strap: 12 In Dia Muffler Pntd
2
42.0802205
19
Clamp, Turbo 5 in.
1
42.1501967
20
Clamp: T-Bolt 8 In.
1
42.1541455
21
Hose Clamp, 128hs
1
46.10194
22
Washer: Flat 5/8 In. Std
1
900498
23
Washer - Flat 3/8 in. SAE
5
901105
24
Hhdblt - G5 5/8-11 x 1-1/2
1
901619
25
Hhdblt - G5 5/16 x 1-1/2
2
902920
26
Carblt - 3/8-16 x 1 1/4 in.
5
903693
27
Nut: Hex Nylon Lk 3/8-16
5
906400
28
Washer: Stainless Steel Flat 3/8 In.
8
907380
29
Hhdnut, 3/8-16 Stainless Steel
4
907386
30
Hhdnut, 5/16-18 Stainless Steel Nylock
2
907390
31
Hhdnut, 1/2-13 Stainless Steel Nylock
8
907392
32
Washer, 1/2 Stainless Steel Flat
16
907395
33
Lockwasher, 5/8 Stainless Steel
1
907419
34
Hhdblt, 1/2-13 x 1-1/2 Stainless Steel
4
907424
35
Hhdblt, 1/2-13 x 1-1/4 Stainless Steel
4
907563
36
Hhdblt Stainless Steel 3/8-16 x 2-3/4
4
907565
37
LX1214
- 47 -
42.0802220A Issue Date: 08/14
Section 3
3.03 Cummins Engine Air Intake and Exhaust Assembly
