04 lower beater bar assembly – Ag-Bag LX1214 User Manual
Page 223
Description
Quantity
Part No.
Item
Hhdblt, 1/2-13 x 5-1/4 Gr 8 YZ
4
908625
1
Nut, Hex Lock, 5/8-11 Nylock
8
906402
2
Nut, Hex Lock, 1/2-13 Nylock
4
906401
3
Nut, Hex Lock, 3/4-10 Nylock
2
906349
4
Grease Zerk, 1/8 in. NPT Female
1
905501
5
Bolt, Hex, 5/8-11 x 2-1/2 in. Gr 5
8
903832
6
Bolt, Hex, 3/8 x 1 in. Gr 5 Yellow Zinc
3
902300
7
Washer, Flat, 3/8 in. SAE
3
901105
8
Washer, Lock, 3/8 in.
3
900504
9
Washer, Flat, 3/8 in.
1
900499
10
Nut, Hex, 3/8-16
2
900366
11
Sprocket, 100B17 2-3/16 in. 1/2 in. Key
1
42.1520672
12
Bearing, 2-3/16 in., 4 Bolt Flange
2
42.1510037
13
Keystock, Square, 1/2 in. x 3 in. Long
1
42.1120074
14
Bracket Weldment, Chain Tensioner Spring Loaded
1
42.1020075
15
Spacer, Beater Chain Tensioner Bracket
1
42.1020072
16
Tensioner, Beater Chain, 3-1/4 in. x 3 in. UHMW
1
42.1020064
17
Chain, Roller #100H Super RVT UST 60P
1
42.0901357
18
Link, #100H Connector UST
1
42.1520342
18a
Shaft, Stub Idle
1
42.0901229
19
Shaft, Stub Drive
1
42.0901227
20
Beater, Lower Weldment
1
42.0901223
21
Nipple, 1/8 in. x 3 in. Stainless Steel
1
42.0800945
22
Guard, Beater Bar Chain Roller
1
42.0800943
23
Spring, Ext 1 x 4.50 in.
1
340077B1
24
Rod, 3/8 in. x 5.5 in. Belt Tensioner
1
336977B1
25
Spacer: Tube
4
42.0802291
26
LX1214
- 223 -
42.0802220A Issue Date: 08/14
Section 8
8.04 Lower Beater Bar Assembly
