01 hydraulic tank assembly – Ag-Bag LX1214 User Manual
Page 261
Description
Quantity
Part No.
Item
Tank, Hydraulic Wld
1
42.0800406.8
1
Filter Asm, Return Tank 4215/4240
2
21.42085
2
Filter Element
2
21.42585
2a
Filter Asm, Top Tank Case Drain
1
21.20850
3
Filter
1
21.21112
3a
Gasket
1
21.21115
3b
O-Ring
1
21.21113
3c
Elbow: 2 in. 45 Deg Female
1
42.0802223
4
Gauge, Filter Minder
3
32.00941
5
Elbow, 1/8 FPT x 1/8 MPT
3
32.60003
6
Plug - Hex Head #8mp
1
42.1540407
7
Cap - Fuel, N2
1
21.30210
8
Elbow -90d 3/8 in. Tube - 3/8 in. NPT
2
21.20879
9
Tubing - Clear 3/8 in. Nom (Order Per Foot)
1 Ft
21.20878
10
Nipple, Pipe 1 x 5
2
42.0800507
11
Strainer - Hyd. Tank Fill
1
21.30278
12
Valve, Ball 2 in.
1
908078
13
Valve, Ball 1 in.
2
908077
14
Adapter, 2 in. MPT x 2 in. MJIC
1
32.03893
15
Plug, -16 ORB
3
32.02638
16
Adapter - 1/2 M JIC x -16 ORB
1
32.02103
17
Adapter, 3/4 MJIC x -16 ORB
4
32.01955
18
Elbow, 3/4 MJIC x Swivel 90
2
32.01941
19
Decal, Oil Level Hyd. Res.
1
21.20881
20
O-Ring - M10 x 1 W/retainer
1
908132
21
Cap, -16 Jic W/ 10mm Port
1
42.0800895
22
Sensor, Temperature
1
42.0800272
23
Tee, 1 in. Swivel Run JIC
1
32.03190
24
Elbow - 45 16 MJIC x 1 in. NPT
2
908011
25
Fitting, 1/2 MPT x 5/8 HB Brass
2
21.00370
26
Clamp, .437 in.-1.000 in. Hose
2
07.11696
27
Elbow, 1/2 NPT Street 90d
2
21.20947
28
Filter, Oil Tank Breather
1
21.20848
29
Bushing, 3/4 x 1/2 Stainless Steel
1
32.00698
30
Mount - Breather
1
42.0901505
31
Adapter, Breather Filter
1
21.20849
32
Hose, Heater 5/8 in. (Order Per Foot)
6 Ft
32.60740
33
Adapter, 1/2 M JIC To 1/2 MPT
1
07.17862
34
Mach Bshg - 1-1/4
1
900512
35
Nipple, 2 in. Stainless Steel Close
1
32.00785
36
Hhdblt, Stainless Steel 3/8-16 x 1-1/4
8
907425
37
LX1214
- 261 -
42.0802220A Issue Date: 08/14
Section 10
10.01 Hydraulic Tank Assembly
