05 hyd tube asm – Ag-Bag LX1214 User Manual
Page 271
Description
Quantity
Part No.
Item
Hyd Tube Kit, X1114 Tow
1
42.0801053
1
Cross - Union -08 JIC
2
908131
2
Plate, Cover 1/2 Tube Clamp
52
42.1541728
3
Clamp - Insert Sgl 1/2t Set
79
42.1541251
4
Clamp, Insert Sgl 3/4t Set
16
42.1541252
5
Clamp, Top Sgl 1/2p 3/4t 1t
16
42.1541726
6
Hhdblt, 1/4-20 x 1-1/2 Stainless Steel
60
907458
7
Hhdblt - Stainless Steel 1/4-20 x 5-1/2
8
907973
8
Hhdblt, Stainless Steel 1/4-20 x 3
30
907496
9
Hhdblt, 1/4-20 x 2 Stainless Steel
32
907423
10
Elbow 90d Union 3/4-16 37 Deg
5
09.74150
11
Tee, Union, 3/4-16 37d JIC
8
09.74123
12
Elbow, 90 1/2 in. JIC Swivel
3
09.74149
13
Union, Bulkhead #8 MJ x #8 MJ
20
42.1540591
14
Nut, Bulkhead Union
20
42.1540750
14a
Connector - #8 MJ x #4 FP
14
42.1541405
15
Connector: 1/4 MPT x 1/4 Tube
1
908477
16
Reducer, 3/4 FJIC x 3/8 MJIC
4
32.60628
17
Adapter, 1/2 FJIC x 3/8 FPT
6
32.04687
18
Union, -12 Male JIC
4
907557
19
Connector: 3/8 MPT x 3/8 Tube
6
908480
20
Connector: 1/4 MPT x 3/8 Tube
8
908479
21
Elbow, 3/4 MJIC x Swivel 90
2
32.01941
22
Adapter, 3/4 F JIC To 1/2 M JIC
3
32.01948
23
Elbow: 1/4 MPT x 3/8 Tube
5
908468
24
Tee, -12 Male JIC
3
32.03049
25
Tee, 3/4 Swivel Run 37 Flare
3
32.01945
26
Adapter, 1/2 F JIC x 3/8 M JIC
2
32.03057
27
Hhdblt, 1/4-20 x 4 Stainless Steel
2
908542
28
LX1214
- 271 -
42.0802220A Issue Date: 08/14
Section 10
10.05 Hyd Tube Asm
