05 asm: wheel column ee fts – Ag-Bag LX1214 User Manual
Page 23
Description
Quantity
Part No.
Item
Adapter, 1/2 M JIC To 1/2 MPT
3
07.17862
1
Adapter, 3/4 F JIC To 1/2 M JIC
2
32.01948
2
Spring, Brake
1
42.0800836
3
Brake Shoe, Modified
2
42.0800849
4
Wdmt: EE FTS Wheel Column
1
42.0802274.8
5
Drum, Brake - Machined
1
42.1010057.8
6
Spider, Brake (mod Valmet)
1
42.1010058
7
Stud, Wheel Drive - Class 5
8
42.1201000
8
Bracket, S Cam Shaft - Wheel Brake
1
42.1201012.8
9
Drive, Wheel Class 5 Blk Bruin - Mchnd
1
42.1201018.5
10
Ring, Wheel Column Retaining 5 in.
1
42.1201021
11
Spacer - Wheel Column, Brnz
1
42.1201023
12
Plate, S Cam Brkt Clmn Mnt
1
42.1201203.8
13
Bushing, Brake Shoe Pin
2
42.1501178
14
Pin, Brake Shoe
2
42.1501178
15
Roller, Brake Shoe
2
42.1501178
16
Ring, Snap
4
42.1501178
17
Washer, Brake Shoe
6
42.1501178
18
Adjuster, Slack
1
42.1501180.8
19
Cam, S
1
42.1501181
20
Can, Air
1
42.1501184.8
21
Clevis, Air Can (Includes Pins)
1
42.1501185
22
Pin (Included With Clevis)
1
906507
22a
Pin (Included With Clevis)
1
900529
22b
Seal, Cam Brake
1
42.1501189
23
Bushing, Cam
1
42.1501190
24
Adapter, Black Bruin 12f4omxs
2
42.1540321
25
Adapter, Black Bruin 8f4omxs
1
42.1540355
26
Nut - Lug Flanged 3/4 in. NF W183
8
42.1550151
27
Sochdblt - 12mmx90mm G12.9 Din912
10
42.1550360
28
Washer, Cam
4
42.1550380
29
Ring, Snap
1
42.1550381
30
Hhdnut - M12-1.75 Jam
10
42.1550411
31
Hhd Jam Nut, 5/8-18 Fin
1
900360
32
Hhdnut - 5/8-11
2
900371
33
Washer - Lock, 1/2
4
900506
34
Lockwasher, 5/8 Yellow Zinc
10
900508
35
Hhdblt - 3/8-16 x 1-3/4 G5
2
901296
36
Hhdnut - Lock 3/8 Whiz
2
903437
37
Nut: Hex Nylon Lk 3/8-16
2
906400
38
Shcs, 3/8-16 x 1-1/4 in.
16
907298
39
LX1214
- 23 -
42.0802220A Issue Date: 08/14
Section 1
1.05 Asm: Wheel Column EE FTS
