20 liquid applicator tank assembly – Ag-Bag LX1214 User Manual
Page 209
Description
Quantity
Part No.
Item
Bolt, Button Hd. #10-24 x 1-1/2 in. Stainless Steel
4
907637
2
Nut, Hex Lock, #10-24 Nylock Stainless Steel
4
907621
4
Washer, Flat, #10 Stainless Steel
5
907494
5
Bolt, Hex, 5/16-18 x 3/4 in. Stainless Steel
12
907463
6
Washer, Lock, 5/16 in. Stainless Steel
12
907411
7
Nut, Hex Lock, 1/4-20 Nylock Stainless Steel
4
907389
8
Washer, Flat, 5/16 in. Stainless Steel
12
907379
9
Washer, Flat, 1/4 in. Stainless Steel
4
907234
10
Bracket, Inoculant Tank, Bottom
1
42.0801036
21
Bracket, Inoculant Tank, Front
1
42.0800991
22
Tank, Inoculant 56 Gal
1
42.0800222
23
U-Bolt, 1/4 in. x 1-1/4 in. x 2-1/4 in.
2
09.74201
25
Valve, Throttling 23520, 3/4 in.
1
07.17893
27
Cap, CP25607-1 Nylon Black
1
07.17837
28
Strainer, 122, 1-3/4 in. PP 50 Mesh
1
07.17537
29
Filter Bowl
1
07.17827
29a
Gasket
1
07.17540
29b
Screen
1
07.17539
29c
Adapter, QJ1/4TT- NYB
1
07.17270
30
Gasket, Cap EPDM CP19438-EPR
1
07.15790
32
Elbow, 90° Swivel 1/2 in. FPT x 3/8 in. Hose Barb
2
07.15046
33
Tee, Hose Barb, 3/8 in. Polypro
1
07.13368
35
Elbow, Street 90° 3/4 in.
1
07.13032
36
Clamp, .375 in.-.875 in. Hose
11
07.11695
38
Agitator, Nylon T-10 VH Complete
1
07.11639
39
Hose Shank, Tee Jet, 3/8 in. Nylon
1
07.11259
40
Straight, 3/4 in. PT x 3/8 in. Hose Barb Nylon
1
07.10353
42
Straight, 1/4 in. PT x 3/8 in. Hose Barb Nylon
1
07.10341
43
Elbow, 90° 3/4 in. MPT x 3/8 in. Hose Barb
2
07.10307
45
Pump, Shurflo 3.0 GPM
1
07.05114
49
LX1214
- 209 -
42.0802220A Issue Date: 08/14
Section 7
7.20 Liquid Applicator Tank Assembly
