03 upper beater bar assemby – Ag-Bag LX1214 User Manual
Page 221
Description
Quantity
Part No.
Item
Hhdblt, 1/2-13 x 5-1/4 Gr 8 YZ
4
908625
1
Hhdnut, 5/8-11 Nylock
8
906402
2
Hhdnut - Nylon Lk 1/2-13
4
906401
3
Hhdblt, Gr 5, 5/8-11 x 2-1/2
4
903832
4
Hhdblt, G5 1/2-13 x 2
2
902050
5
Hhdblt, 5/8-11 x 5-1/2 Gr 5
4
901264
6
Washer: Flat 5/8 In. Std
4
900498
7
Bearing - 2-3/16 4-Bolt Flange
1
42.1510037.8
8
Spacer, Beater Bar Motor Mount
8
42.1120058
9
Bearing - 2-3/16 4-Bolt Flange
1
42.1020035
10
Mount, Beater Bar Hyd. Motor
1
42.1020009
11
Beater, Upper Wldmnt
1
42.0901232.5
12
Shaft, Stub Idle
1
42.0901229
13
Shaft - Splined Upper Beater
1
42.0901073
14
Hyd Motor - 32.7 Cu In
1
42.0800424.5
15
Seal Kit - Hydraulic Motor
1
42.1541901
15a
Valve, Hyd Beater
1
42.0800254
16
Relief Valve, Beater
1
42.0801284
16a
Seal Kit - Relief Valve
1
42.0801285
16b
Coil, Beater Valve
2
42.0801286
16c
Coil Nut, Beater Valve
2
42.0801287
16d
Seal Kit - Beater Valve
1
42.0801288
16e
Adapter, -10 ORB x 1/2 M JIC
2
32.02101
17
Elbow, 90 1/2 in. JIC Swivel
4
09.74149
18
Spacer: Tube
4
42.0802291
19
LX1214
- 221 -
42.0802220A Issue Date: 08/14
Section 8
8.03 Upper Beater Bar Assemby
